| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Power output | 7,537 kW | Electrical efficiency | 33.56% |
| Exhaust gas temperature | 507 °C | Exhaust gas flow | 26.61 kg/s |
| Natural gas consumption | 2,378 Nm³/h | Heat rate | 10,727 kJ/kWh |
| Item | Specification |
|---|---|
| Gas turbine skid dimensions | 10.8 × 2.8 × 3.7 m (reference; inlet filtration system not included) |
| Maintenance clearance | Left side: 3 m; Right side: 3 m; Front: 4.3 m |
| Weight | 63 t |
| CHP Output | Rated Value |
|---|---|
| Steam production | 14.9 t/h |
| Hot-water production | 229.1 t/h |
| Drying heat | 11,220 kW |
[1] Rated-state parameters are based on standard conditions of 15 °C, 101.325 kPa, and 60% relative humidity. Fuel performance is based on natural gas with a lower heating value (LHV) of 34 MJ/Nm³.
[2] When looking from the gas turbine toward the exhaust end, the left-hand side is defined as the left side of the unit and the right-hand side as the right side.
[3] Steam production is based on steam pressure of 0.8 MPa(g) and steam temperature of 175 °C.
[4] Hot-water production is based on an inlet-water temperature of 15 °C, outlet-water temperature of 60 °C, and exhaust-gas outlet temperature of 75 °C.
[5] Drying heat is based on available exhaust-gas heat above 120 °C.
The source specification includes curves showing how unit power output and heat rate vary with inlet-air temperature. The curves are retained conceptually as part of the technical specification; numerical curve points are not separately tabulated in the source document.
